Greater Lift Height
Provides extended vertical travel for multi-level handling requirements.
MARCO Lift Tables
Multi-Stage Vertical Lift Tables
Stable vertical lifting for pallets, goods and work platforms
Platform size, lift height and capacity configured to the application
Suitable for integration into industrial material-flow systems
MARCO High-Lift Scissor Tables
Multi-Stage Vertical Lift Tables
Multi-stage electro-hydraulic scissor tables for applications requiring greater vertical travel than a standard single-scissor lift table.
Up to 5,000 kg
Model-dependent capacity
Model-dependent capacity
Multiple metres
Extended vertical travel
Extended vertical travel
Multi-stage
Stacked scissor construction
Stacked scissor construction
Flexible installation
Surface-mounted or pit-recessed
Surface-mounted or pit-recessed
Stable vertical lifting for pallets, goods and work platforms
Platform size, lift height and capacity configured to the application
Suitable for integration into industrial material-flow systems
Extended Vertical Travel
What Is a High-Lift Scissor Table?
A high-lift scissor table uses two or more scissor mechanisms stacked vertically to provide a greater lifting height than a standard single-scissor table. The multi-stage arrangement raises loads between different working levels while maintaining a compact footprint.
These tables can be engineered for vertical goods transfer, elevated work positioning, pallet handling and other applications where long lift travel is required without installing a conventional lift shaft.
Stable Movement
Rigid multi-scissor construction supports controlled vertical lifting.
Application-Specific
Capacity, platform and travel can be configured around the load and site.
System Integration
Suitable for standalone use or integration into material-flow systems.
Technical Overview
High-Lift Table Configuration
High-lift tables are selected according to the load, required travel, platform dimensions, duty cycle and installation environment.
| Feature | Typical Available Configuration |
|---|---|
| Lifting capacity | Up to 5,000 kg, depending on model and configuration |
| Vertical travel | Multiple metres, according to the number and geometry of scissor stages |
| Platform | Standard, extended or custom-fabricated platform |
| Installation | Surface-mounted or pit-recessed |
| Operation | Electro-hydraulic control system |
| Safety arrangement | Specified for the application and may include guarding, gates, emergency stops and overload protection |
Final capacity, platform dimensions, lift height and safety provisions are confirmed following an application and site assessment.
Typical Uses
Applications for High-Lift Scissor Tables
Designed for controlled vertical movement in manufacturing, warehousing and commercial facilities.
Vertical Goods Transfer
Move palletised goods or materials between different working levels.
Mezzanine Loading
Support controlled loading and unloading at mezzanine or raised-floor levels.
Elevated Work Positioning
Position loads or properly designed work platforms at elevated levels.
Pallet Handling
Raise and lower pallets where longer vertical travel is required.
Production Integration
Connect processes operating at different heights within a production area.
Warehouse Operations
Improve vertical material flow in storage and distribution environments.
Need a high-lift table for your site?
Tell us the load, required travel, platform size and operating environment. Our team will help specify the correct MARCO high-lift table and safety arrangement.
