Better Ergonomics
Raises work to a suitable height for packing, assembly and handling tasks.
HYMO Lift Tables
Economy Scissor Lift Tables
EAX Series
A reliable and cost-effective hydraulic lift table for creating an ergonomic working height in assembly, packing, production and general material-handling applications.
1,000–2,000 kgAvailable lifting capacities
800 mmFixed lifting stroke
3Standard configurations
From 200 mmLow closed height
- ✓Stable single-scissor construction
- ✓Standardised models for excellent value and availability
- ✓Designed for dependable industrial work positioning
Ergonomic Work Positioning
What Is an Economy Scissor Lift Table?
The HYMO EAX is a fixed-configuration hydraulic scissor lift table developed for workplaces that need a practical way to raise loads to a comfortable handling height. It helps position products, components and containers closer to the operator, reducing repeated bending and unnecessary manual handling.
The economy range uses proven standard dimensions and capacities instead of custom-built configurations. This makes it a straightforward choice for businesses seeking reliable lifting performance, competitive pricing and faster availability.
Stable Lifting
Robust scissor construction supports controlled vertical load movement.
Low Closed Height
Closed heights from 200 mm help simplify loading and workplace integration.
Economy Range
Standard models deliver dependable performance without unnecessary customisation.
Model Range
HYMO EAX Specifications
Choose from three standard configurations with capacities of 1,000 kg or 2,000 kg.
| Model | Capacity | Lift Stroke | Closed Height | Platform Width | Platform Length |
|---|---|---|---|---|---|
| EAXC10-8/6-N | 1,000 kg | 800 mm | 200 mm | 800 mm | 1,200 mm |
| EAXC10-8/6-N-230 | 1,000 kg | 800 mm | 200 mm | 800 mm | 1,200 mm |
| EAXC20-8/6-N | 2,000 kg | 800 mm | 220 mm | 800 mm | 1,350 mm |
Specifications are based on the standard economy range and may be subject to manufacturer updates. Contact our team to confirm the correct model for your application.
Typical Uses
Applications for Economy Lift Tables
A versatile lifting solution for routine work positioning across industrial and logistics environments.
Packing Stations
Position cartons, products and materials at a more practical packing height.
Assembly Areas
Raise components to support more comfortable and efficient assembly work.
Production Lines
Maintain an appropriate transfer or working height within production processes.
Goods In and Out
Support regular handling operations in warehouse receiving and dispatch areas.
Work Positioning
Lift loads vertically where fixed ergonomic height adjustment is required.
Manufacturing
Handle materials and parts in light- to medium-duty industrial applications.
Need help selecting a lift table?
Tell us the load weight, platform size and working height you require. Our team will help identify the most suitable HYMO lift table for your operation.
