Ergonomic Positioning
Bring loads to a practical working height and reduce unnecessary bending or reaching.
MARCO Lift Tables
Single Scissor Lift Tables
Industrial Lifting and Work Positioning
Versatile electro-hydraulic lift tables for raising, lowering and positioning loads at a safe working height across production, packing and material-handling operations.
500–10,000 kgFull standard capacity range
500–2,000 mmAvailable lift stroke
Up to 3,000 × 2,000 mmPlatform dimensions
Single scissorStable vertical movement
✓Smooth height adjustment for ergonomic work positioning
✓Compact closed heights simplify loading and unloading
✓Standard configurations plus application-specific solutions
Everyday Industrial Lifting
What Is a Single Scissor Lift Table?
A single scissor lift table uses one scissor mechanism to move a platform vertically. It provides a stable way to raise goods, pallets, components or workpieces to the height required for handling or production.
The range is suited to applications where the required stroke can be achieved within a single scissor geometry. MARCO notes that the maximum stroke is normally related to platform length; applications requiring substantially greater travel are generally served by a high-lift model.
Stable Lifting
Rigid scissor construction supports controlled vertical movement during operation.
Broad Model Range
Capacities, lift strokes and platform sizes are available for varied industrial duties.
System Integration
Suitable for standalone workstations or integration into production and logistics flows.
Featured Configurations
MARCO Single Scissor Table Models
Four commonly specified configurations covering light to medium-duty lifting requirements.
| Model | Capacity | Lift Stroke | Closed Height | Platform Width | Platform Length |
|---|---|---|---|---|---|
| M0 005050-D1 | 500 kg | 500 mm | 180 mm | 650 mm | 850 mm |
| M1 010090-D2B | 1,000 kg | 900 mm | 220 mm | 1,200 mm | 1,350 mm |
| M3 020160-D2B | 2,000 kg | 1,600 mm | 300 mm | 1,500 mm | 2,250 mm |
| M3 030160-D2 | 3,000 kg | 1,600 mm | 300 mm | 1,200 mm | 2,250 mm |
The wider MARCO standard range includes capacities up to 10,000 kg. Final model, platform dimensions, duty cycle and safety provisions are confirmed following an application assessment.
Typical Uses
Applications for Single Scissor Tables
A flexible lifting solution for manufacturing, warehousing and general material-handling environments.
Packing and Assembly
Position goods and components at a comfortable height for repetitive tasks.
Production Lines
Raise or lower workpieces to connect processes operating at different heights.
Goods In and Dispatch
Support controlled handling during receiving, sorting and despatch operations.
Pallet Handling
Position palletised loads for easier access during loading and unloading.
Machine Feeding
Present materials at the required level for loading into machinery or processing equipment.
Warehouse Workstations
Create an adjustable-height station for handling, inspection or order preparation.
Need a single scissor table for your site?
Tell us the load, required lift height, platform size and operating environment. Our team will help specify the correct MARCO table and safety arrangement.
